| Vehicle Parameters | Overall Dimension(L x W x H) | 6000*2050*2510mm |
| Curb Weight: | 5670Kg | |
| GVW: | 8210Kg | |
| Wheelbase: | 3360mm | |
| Drive Type: | 4x2 | |
| Engine | Engine Model: | 4KH1-TCG40 |
| Engine Power: | 88Kw | |
| Delivery Capacity: | 2999(ml) | |
| Horsepower: | 120PS | |
| Transmission | Transmission: | MSB-5SM |
| Forword Gear: | 5 Speed Gear | |
| Backward Gear: | 1 Speed Gear | |
| Chassis | Front Wheel Distance: | 1504mm |
| Rear Wheel Distance: | 1425mm | |
| Axle Loads: | Double Axles | |
| Rear Axle Ratio: | 6.142 | |
| Tires: | 7(Including Spare Tire) | |
| Tire Model: | 7.00R16 14PR | |
| Seats | Front Seat: | 2 |
| Configuration | 1 | Power Steering |
| 2 | AC | |
| 3 | Retro-reflective Marking | |
| 4 | Radial Tire | |
| 5 | ABS | |
| 6 | Free Maintenance Battery | |
| Sweeper Body: | Cleaning Width： | 3m |
| Working Speed： | 3~20Km/h | |
| Water Tank Max.Volume: | 1000L(Stainless Steel) | |
| Dust Bin Effective Volume: | 2500L(Stainless Steel) |
