| Chassis Dimensions and Parameters | Overall Dimension(L x W x H) | 8550x2500x3450mm |
| Wheelbase: | 3985+1370mm | |
| Front Wheel Distance: | 2065mm | |
| Rear Wheel Distance: | 1855/1855mm | |
| Rear Axle Ratio: | 5.571 | |
| Leaf Spring: | 8月10日 | |
| Weights and Capacities | Curb Weight: | 14220Kg |
| GVW: | 25000Kg | |
| Axle Loads: | 7000/18000kg | |
| Engine | Engine Model: | 6WG1-TCG52 |
| Max output: | 308Kw | |
| Displacement: | 9839ml | |
| Horsepower: | 420Ps | |
| Exhaust Gas Treatment Technology： | SCR | |
| Without VGT | ||
| Transmission | Transmission: | ZF8S2030T0 |
| Forward Gear: | 8 Speed Gear | |
| Backward Gear: | 1 Speed Gear | |
| Brake | Air Brake | |
| Front Drum Back Drum | ||
| With Exhaust Brake | ||
| Cab | Cabin Type: | Plat Roof One Sleeper |
| Number of Seats: | 2 | |
| Chassis | Drive Type: | 6x4 |
| Tires: | 11(Including Spare Tire) | |
| Tire Model: | 12R22.5 18PR | |
| Fuel Tank | Number: | 1 |
| Capacity: | 400L | |
| Tops Parameters | Dump Body Parameter | 5600x2300x1500mm |
| Hydraulic Cylinder | Middle lifting | |
| Thickness of the dump body | Bottom 8mm, Side 6mm | |
| Configurations: | Power Steering | |
| Air Conditioner | ||
| Tubeless Tire | ||
| ABS | ||
| Free Maintenance Battery | ||
| Central Lock | ||
| Power Window | ||
| Data Recorder | ||
| PTO | ||
| Air Suspension Seat | ||
| Air Suspension Cabin | ||
| Front Chrome Plate Kit | ||
| Aluminum Alloy Fuel Tank | ||
