| Chassis Dimensions and Parameters | Overall Dimension (L x W x H) | 9892×2520×3997mm |
| Wheelbase | 1850+2980+1370 mm | |
| Front Wheel Distance | 2060/2060mm | |
| Rear Wheel Distance | 1855/1855mm | |
| Front/Rear Suspension | 1370/1100mm | |
| Rear Axle Ratio | 5.571 | |
| Approach/Departure angle | 25/25 | |
| Leaf Spring | 2004/4/5 | |
| Weights and Capacities | Curb Weight | 14000kg (varies to final design) |
| Payload | 30870kg (varies to final design) | |
| GVW | 45000kg | |
| Axle Loads | 9000/9000/13750/13750 Kg | |
| Engine | Engine Model | 6UZ1-TCG61 |
| Cylinder | 6 Cylinders in line | |
| Engine Features | Turbocharging, inter | |
| cooling. | ||
| high-pressure common-rail | ||
| diesel injection system | ||
| liquid-cooled engine. | ||
| Torque(N.m) | 1800 | |
| Max output | 279KW | |
| Displacement | 9839ml | |
| Horsepower | 380Ps | |
| Exhaust Gas Treatment Technology | SCR+DPF | |
| Transmission | Transmission | ZF8S |
| Forward Gear | 8 Speed Gear | |
| Backward Gear | 1 Speed Gear | |
| Brake | Air Brake | |
| Front Drum Back Drum | ||
| With Exhaust Brake | ||
| Generator | 24V | |
| Cab | Number of Seats | 2 |
| Cabin Type | Standard Roof One Bed | |
| Drive Type | 8x4 | |
| Tires | 13(Including Spare Tire) | |
| Tire Model | 12R22.5 18PR | |
| Fuel Tank | Number | 1 |
| Capacity | 400L | |
| Configurations | 1 | Power Steering System |
| 2 | Air Conditioning | |
| 3 | Central Lock | |
| 4 | Power Window | |
| 5 | Driving Data Recorder | |
| 6 | Tubeless Tire | |
| 7 | ABS | |
| 8 | Free Maintenance Battery | |
| 9 | Aluminum Alloy Gas Tank | |
| 10 | Widened Bumper | |
| 11 | Air Suspension Cabin | |
| 12 | Air Suspension Seat | |
| Mixer Body | Brand | KYOKUTO |
| Agitating capacity | 12m3 | |
| Material | B480 | |
| Reduction gearbox | PMP PMB 7.1(Italy) | |
| Pump | PMP PMH P90(Italy) | |
| Motor | PMP PMH M90(Italy) | |
