| Wheelbase (mm) | 4600 | ||
| Drive Type | 4x2(left hand drive) | ||
| Chassis dimension(L*W*H) | Dimension(mm) | 8000*2540*3055 | |
| Chsssis Parameters | GVW (kg) | 21000 | |
| Curb Weight (kg) | 7030 | ||
| Pay Load (kg) | |||
| Driver & Passenger | 2 | ||
| Engine | Model | 6UZ1-TCG50 | |
| Type |
6 Cylinders in line, high presure, electrical common-rail diesel fuel injection system, water cooling , turbo charging, inter cooling. |
||
| Displacement (L) | 9.839 | ||
| Rated Power kw(hp) | 279Kw(380hp) | ||
| Forward gear | 12 speed gear | ||
| Backward gear | 2 speed gear | ||
| Front wheel distance | 2065 | ||
| Rear wheel distance | 1855 | ||
| Axle Loads | 8000/13000 | ||
| Front/Rear suspention | 1370/2030 | ||
| Approach/departure angle | 17/23 | ||
| Leaf spring | 8/8+6 | ||
| Tires | 7(including spare tire) | ||
| Tire model | 315/80R22.5 20PR | ||
| Fuel tank | 400L | ||
| Brake System | Air /Oil | Air Brake | |
| Max. Speed (km/h) | 100 | ||
